PBG型屏蔽式管道泵-概述
采用的水力模型,根据IS型离心泵之性能参数和立式泵的独特结构组合设计,并严格按照国际ISo2858进行设计制造,该产品轴封选用硬质合金机械密封装置,具有高效节能、性能可靠、安装使用方便等特点。
PBG型屏蔽式管道泵-主要特点
运行平稳:泵轴的同心度及叶轮优异的动静平衡,保证平稳运行,绝无振动。
滴水不漏:不同材质的硬质合金密封,保证了不同介质输送均无泄漏。
噪音低:两个低噪音的轴承支撑下的水泵,运转平稳,除电机微弱声响,基本无噪音。
故障率低:结构简单合理,关键部分采用国际品质配套,整机无故障工作时间大大提高。
维修方便:更换密封、轴承、简易方便。
占地更省:出口可向左、向右、向上三个方向,便管道布置安装,节省空间。
PBG型屏蔽式管道泵-产品概述:
PBG型屏蔽式管道泵,吸收了国际上屏蔽泵设计及制造的技术,将电机的屏蔽技术应用于流体输送领域,为适应国内市场需求而推出的系列化新产品。PBG型屏蔽式管道泵系列性能参数基本符合国际标准IS02858及国家标准JB/T6878.2-93的规定。具有设计规范,通用化程度高,结构合理,性能稳定,运转低噪音,无振动等显著特点,是替代常规卧式离心泵,立式管道泵的理想产品。全系列共67个品种,184个规格,其性能范围:流量6.3~1080m3/h,扬程12.5~125m,配用电机功率0.37~160kW,转速1450r/min和2900r/min。
PBG型屏蔽式管道泵-产品特点:
①泵结构紧凑,机泵一体化,体积小。其立式结构具有安装占地面积小,运行平稳,安装无需调整。
②泵进出口设计成规格相同法兰,且位于同一中心线上,可象阀门一样直接安装在管路上,且中心低,便于管道布置,安装特别方便。
③泵与电机同轴,轴向尺寸短,使泵运行更加平稳,噪音低。
④取消传统轴封方式,避免了输送介质的外泄,因此具有完全无泄漏的显著特点。
⑤用滑动轴承替代常规电机滚动轴承,使泵具有运行特别平稳,振动噪音极低。
⑥安装检修方便,无需拆动管路系统,只要拆下连接体螺母即可抽出全部转子部件进行检查和维修。
⑦可根据使用要求即流量和扬程的需要进行泵的串、并联运行方式。
PBG型屏蔽式管道泵-主要用途:
①PBG型屏蔽式管道泵普通型供输送清水及物理化学性质类似于清水的其他液体之用。介质使用温度不超过80℃,适用于工业和城市给排水,高层建筑增压送水、园林喷灌、消防增压、远距离输送、暖通制冷循环、浴室等冷暖水循环增压及设备配套。特别适用对振动、噪音要求较高的场合,如地下泵房、空调制冷系统等。
②PBG型屏蔽式管道泵热水型主要供输送温度不超过160℃不含固体颗粒的软水之用,适用于能源、冶金、化工、纺织、造纸以及宾馆、饭店、浴室、锅炉热水增压循环输送及城市采暖系统循环等场合。
③PBG型屏蔽式管道泵防腐型供输送不含固体颗粒,具有腐蚀性,粘度类似于水的液体,适用于石油、化工、冶金、电力、造纸、食品、制药和合成纤维等部门。
PBG型屏蔽式管道泵-型号意义:
PBG型屏蔽式管道泵性能参数 | |||||||
PBG40-100 |
6.3 |
1.75 |
12.5 |
54 |
1450 |
0.55 |
3.5 |
PBG40-100A |
5.6 |
1.56 |
10 |
52 |
1450 |
0.37 |
3.5 |
PBG40-125 |
6.3 |
1.75 |
20 |
46 |
1450 |
1.1 |
3.5 |
PBG40-125A |
5.6 |
1.56 |
16 |
45 |
2900 |
0.75 |
3.5 |
PBG40-160 |
6.3 |
1.75 |
32 |
40 |
2900 |
2.2 |
3.5 |
PBG40-160A |
5.9 |
1.64 |
28 |
39 |
2900 |
1.5 |
3.5 |
PBG40-160B |
5.5 |
1.53 |
24 |
38 |
2900 |
1.1 |
3.5 |
PBG40-200 |
6.3 |
1.75 |
50 |
33 |
2900 |
4.0 |
3.5 |
PBG40-200A |
5.9 |
1.64 |
44 |
31 |
2900 |
3.0 |
3.5 |
PBG40-200B |
5.3 |
1.47 |
36 |
29 |
2900 |
2.2 |
3.5 |
PBG40-250 |
6.3 |
1.75 |
80 |
28 |
2900 |
7.5 |
3.5 |
PBG40-250A |
5.9 |
1.64 |
70 |
28 |
2900 |
5.5 |
3.5 |
PBG40-250B |
5.5 |
1.53 |
60 |
27 |
2900 |
4.0 |
3.5 |
PBG40-100(I) |
12.5 |
3.47 |
12.5 |
62 |
1450 |
1.1 |
3.5 |
PBG40-100(I)A |
11 |
3.05 |
10 |
60 |
1450 |
0.75 |
3.5 |
PBG40-125(I) |
12.5 |
3.47 |
20 |
58 |
1450 |
1.5 |
3.5 |
PBG40-125(I)A |
11 |
3.05 |
16 |
57 |
1450 |
1.1 |
3.5 |
PBG40-160(I) |
12.5 |
3.47 |
32 |
52 |
2900 |
3.0 |
3.5 |
PBG40-160(I)A |
11.7 |
3.25 |
28 |
51 |
2900 |
2.2 |
3.5 |
PBG40-160(I)B |
10.4 |
2.89 |
22 |
50 |
2900 |
1.5 |
3.5 |
PBG40-200(I) |
12.5 |
3.47 |
50 |
46 |
2900 |
5.5 |
3.5 |
PBG40-200(I)A |
11.7 |
3.25 |
44 |
45 |
2900 |
4.0 |
3.5 |
PBG40-200(I)B |
10.6 |
2.94 |
36 |
44 |
2900 |
3.0 |
3.5 |
PBG40-250(I) |
12.5 |
3.47 |
80 |
38 |
2900 |
11 |
3.5 |
PBG40-250(I)A |
11.6 |
3.22 |
70 |
38 |
2900 |
7.5 |
3.5 |
PBG40-250(I)B |
10.8 |
3.0 |
60 |
37 |
2900 |
7.5 |
3.5 |
PBG40-250(I)C |
10.0 |
2.78 |
52 |
36 |
2900 |
5.5 |
3.5 |
PBG50-100 |
12.5 |
3.47 |
12.5 |
62 |
1450 |
1.1 |
3.5 |
PBG50-100A |
11 |
3.05 |
10 |
60 |
1450 |
0.75 |
3.5 |
PBG50-125 |
12.5 |
3.47 |
20 |
58 |
1450 |
1.5 |
3.5 |
PBG50-125A |
11 |
3.05 |
16 |
57 |
1450 |
1.1 |
3.5 |
PBG50-160 |
12.5 |
3.47 |
32 |
52 |
2900 |
3.0 |
3.5 |
PBG50-160A |
11.7 |
3.25 |
28 |
51 |
2900 |
2.2 |
3.5 |
PBG50-160B |
10.4 |
2.89 |
22 |
50 |
2900 |
1.5 |
3.5 |
PBG50-200 |
12.5 |
3.47 |
50 |
46 |
2900 |
5.5 |
3.5 |
PBG50-200A |
11.7 |
3.25 |
44 |
45 |
2900 |
4.0 |
3.5 |
PBG50-200B |
10.6 |
2.94 |
36 |
44 |
2900 |
3.0 |
3.5 |
PBG50-250 |
12.5 |
3.47 |
80 |
38 |
2900 |
11 |
3.5 |
PBG50-250A |
11.6 |
3.22 |
70 |
38 |
2900 |
7.5 |
3.5 |
PBG50-250B |
10.8 |
3.0 |
60 |
37 |
2900 |
7.5 |
3.5 |
PBG50-250C |
10.0 |
2.78 |
52 |
36 |
2900 |
5.5 |
3.5 |
PBG50-100(I) |
25 |
6.94 |
12.5 |
69 |
1450 |
1.5 |
3.8 |
PBG50-100(I)A |
22.3 |
6.19 |
10 |
67 |
1450 |
1.1 |
3.8 |
PBG50-125(I) |
25 |
6.94 |
20 |
68 |
1450 |
3.0 |
3.8 |
PBG50-125(I)A |
22.3 |
6.49 |
16 |
66 |
1450 |
2.2 |
3.8 |
PBG50-160(I) |
25 |
6.94 |
32 |
63 |
1450 |
4.0 |
3.8 |
PBG50-160(I)A |
23.4 |
6.5 |
28 |
62 |
1450 |
4.0 |
3.8 |
PBG50-160(I)B |
21.6 |
6.0 |
24 |
58 |
1450 |
3.0 |
3.8 |
PBG50-200(I) |
25 |
6.94 |
50 |
58 |
2900 |
7.5 |
3.8 |
PBG50-200(I)A |
23.5 |
6.53 |
44 |
57 |
2900 |
7.5 |
3.8 |
PBG50-200(I)B |
21.8 |
6.06 |
38 |
55 |
2900 |
5.5 |
3.8 |
PBG50-250(I) |
25 |
6.94 |
80 |
50 |
2900 |
15.0 |
3.8 |
PBG50-250(I)A |
23.4 |
6.5 |
70 |
50 |
2900 |
11.0 |
3.8 |
PBG50-250(I)B |
21.6 |
6.0 |
60 |
48 |
2900 |
11.0 |
3.8 |
PBG50-315(I) |
25 |
6.94 |
125 |
40 |
2900 |
30.0 |
3.8 |
PBG50-315(I)A |
23.7 |
6.58 |
113 |
40 |
2900 |
22.0 |
3.8 |
PBG50-315(I)B |
22.5 |
6.25 |
101 |
39 |
2900 |
18.5 |
3.8 |
PBG50-315(I)C |
20.6 |
5.72 |
85 |
38 |
2900 |
15.0 |
3.8 |
PBG65-100 |
25 |
6.94 |
12.5 |
69 |
1450 |
1.2 |
3.8 |
PBG65-100A |
22.3 |
6.19 |
10 |
67 |
1450 |
1.1 |
3.8 |
PBG65-125 |
25 |
6.94 |
20 |
68 |
1450 |
3.0 |
3.8 |
PBG65-125A |
22.3 |
6.19 |
16 |
66 |
1450 |
2.2 |
3.8 |
PBG65-160 |
25 |
6.94 |
32 |
63 |
1450 |
4.0 |
3.8 |
PBG65-160A |
23.4 |
6.5 |
28 |
62 |
1450 |
4.0 |
3.8 |
PBG65-160B |
21.6 |
6.0 |
24 |
58 |
1450 |
3.0 |
3.8 |
PBG65-200 |
25 |
6.94 |
50 |
58 |
2900 |
7.5 |
3.8 |
PBG65-200A |
23.5 |
6.53 |
44 |
57 |
2900 |
7.5 |
3.8 |
PBG65-200B |
21.8 |
6.06 |
38 |
55 |
2900 |
5.5 |
3.8 |
PBG65-250 |
25 |
6.94 |
80 |
50 |
2900 |
15.0 |
3.8 |
PBG65-250A |
23.4 |
6.5 |
70 |
50 |
2900 |
11.0 |
3.8 |
PBG65-250B |
21.6 |
6.0 |
60 |
49 |
2900 |
11.0 |
3.8 |
PBG65-315 |
25 |
6.94 |
125 |
40 |
2900 |
30. |
3.8 |
PBG65-315A |
23.7 |
6.58 |
113 |
40 |
2900 |
22.0 |
3.8 |
PBG65-315B |
22.5 |
6.25 |
101 |
39 |
2900 |
18.5 |
3.8 |
PBG65-315C |
20.6 |
5.72 |
85 |
38 |
2900 |
15.5 |
3.8 |
PBG65-100(I) |
50 |
13.9 |
12.5 |
73 |
1450 |
3.0 |
4.2 |
PBG65-100(I)A |
44.7 |
12.5 |
10 |
72 |
1450 |
2.2 |
4.2 |
PBG65-125(I) |
50 |
13.9 |
20 |
72.5 |
1450 |
5.5 |
4.2 |
PBG65-125(I)A |
45 |
12.5 |
16 |
71 |
1450 |
4.0 |
4.2 |
PBG65-160(I) |
50 |
13.9 |
32 |
71 |
1450 |
7.5 |
4.2 |
PBG65-160(I)A |
46.7 |
13.0 |
28 |
70 |
1450 |
7.5 |
4.2 |
PBG65-160(I)B |
43.3 |
12.0 |
24 |
69 |
1450 |
5.5 |
4.2 |
PBG65-200(I) |
50 |
13.9 |
50 |
67 |
2900 |
15.0 |
4.2 |
PBG65-200(I)A |
47 |
13.1 |
44 |
66 |
2900 |
11.0 |
4.2 |
PBG65-200(I)B |
43.5 |
12.1 |
38 |
65 |
2900 |
7.5 |
4.2 |
PBG65-250(I) |
50 |
13.9 |
80 |
59 |
2900 |
22.0 |
4.2 |
PBG65-250(I)A |
46.7 |
13.0 |
70 |
59 |
2900 |
18.5 |
4.2 |
PBG65-250(I)B |
43.3 |
12.0 |
60 |
58 |
2900 |
15.0 |
4.2 |
PBG65-315(I) |
50 |
13.9 |
125 |
54 |
2900 |
34.0 |
4.2 |
PBG65-315(I)A |
46.5 |
12.9 |
110 |
54 |
2900 |
30.0 |
4.2 |
PBG65-315(I)B |
44.5 |
12.4 |
100 |
53 |
2900 |
30.0 |
4.2 |
PBG65-315(I)C |
41 |
11.4 |
85 |
51 |
2900 |
22.0 |
4.2 |
PBG80-100 |
50 |
13.9 |
12.5 |
73 |
1450 |
3.0 |
4.2 |
PBG80-100A |
44.7 |
12.4 |
10 |
72 |
1450 |
2.2 |
4.2 |
PBG80-125 |
50 |
13.9 |
20 |
72.5 |
1450 |
5.5 |
4.2 |
PBG80-125A |
45 |
12.5 |
16 |
71 |
1450 |
4.0 |
4.2 |
PBG80-160 |
50 |
13.9 |
32 |
71 |
1450 |
7.5 |
4.2 |
PBG80-160A |
46.7 |
13.0 |
28 |
70 |
1450 |
7.5 |
4.2 |
PBG80-160B |
43.3 |
12.0 |
24 |
69 |
1450 |
5.5 |
4.2 |
PBG80-200 |
50 |
13.9 |
50 |
67 |
2900 |
15.5 |
4.2 |
PBG80-200A |
47 |
13.1 |
44 |
66 |
2900 |
11.0 |
4.2 |
PBG80-200B |
43.5 |
12.1 |
38 |
65 |
2900 |
7.5 |
4.2 |
PBG80-250 |
50 |
13.9 |
80 |
59 |
2900 |
22.0 |
4.2 |
PBG80-250A |
46.7 |
13.0 |
70 |
59 |
2900 |
18.5 |
4.2 |
PBG80-315 |
50 |
13.9 |
125 |
54 |
2900 |
37.0 |
4.2 |
PBG80-315A |
46.5 |
12.9 |
110 |
54 |
2900 |
30.0 |
4.2 |
PBG80-315B |
44.5 |
12.4 |
100 |
53 |
2900 |
30.0 |
4.2 |
PBG80-315C |
41 |
11.4 |
85 |
51 |
2900 |
22.0 |
4.2 |
PBG80-100(I) |
100 |
27.8 |
12.5 |
76 |
1450 |
5.5 |
4.2 |
PBG80-100(I)A |
89 |
24.7 |
10 |
74 |
1450 |
4.0 |
4.2 |
PBG80-125(I) |
100 |
27.8 |
20 |
76 |
1450 |
11.0 |
4.2 |
PBG80-125(I)A |
89 |
24.7 |
16 |
74 |
1450 |
7.5 |
4.2 |
PBG80-160(I) |
100 |
27.8 |
32 |
76 |
1450 |
15.0 |
4.2 |
PBG80-160(I)A |
93.5 |
26.0 |
28 |
74 |
1450 |
11.0 |
4.2 |
PBG80-160(I)B |
86.6 |
24.1 |
24 |
72 |
1450 |
11.0 |
4.2 |
PBG80-200(I) |
100 |
27.8 |
50 |
74 |
1450 |
22.0 |
4.2 |
PBG80-200(I)A |
93.5 |
26.0 |
44 |
73 |
1450 |
18.5 |
5.5 |
PBG80-200(I)B |
87 |
24.2 |
38 |
71 |
1450 |
15.0 |
5.5 |
PBG100-100 |
100 |
27.8 |
12.5 |
76 |
1450 |
5.5 |
5.5 |
PBG100-100A |
89 |
24.7 |
10 |
74 |
1450 |
4.0 |
5.5 |
PBG100-125 |
100 |
27.8 |
20 |
76 |
1450 |
11.0 |
5.5 |
PBG100-125A |
89 |
24.7 |
16 |
74 |
1450 |
7.5 |
5.5 |
PBG100-160 |
100 |
27.8 |
32 |
76 |
1450 |
15.0 |
5.5 |
PBG80-250B |
43.3 |
12.0 |
60 |
58 |
2900 |
15.0 |
4.2 |
PBG100-160A |
93.5 |
26.0 |
28 |
74 |
1450 |
11.0 |
5.5 |
PBG100-160B |
86.6 |
24.1 |
24 |
72 |
1450 |
11.0 |
5.5 |
PBG100-200 |
100 |
27.8 |
50 |
74 |
1450 |
22.0 |
5.5 |
PBG100-200A |
93.5 |
26.0 |
44 |
73 |
1450 |
18.5 |
5.5 |
PBG100-200B |
87 |
27.2 |
38 |
71 |
1450 |
15.0 |
5.5 |
PBG125-100 |
160 |
44.4 |
12.5 |
82 |
1450 |
11.0 |
5.5 |
PBG125-100A |
143 |
39.7 |
10 |
77 |
1450 |
7.5 |
5.5 |
PBG125-125 |
160 |
44.4 |
20 |
80 |
1450 |
15.0 |
5.5 |
PBG125-25A |
143 |
39.7 |
16 |
77 |
1450 |
11.0 |
5.5 |
PBG125-160 |
160 |
44.4 |
32 |
78 |
1450 |
22.0 |
5.5 |
PBG125-160A |
150 |
41.7 |
28 |
76 |
1450 |
18.5 |
5.5 |
PBG125-1160B |
138 |
38.3 |
24 |
73 |
1450 |
15.0 |
5.5 |
PBG125-200 |
160 |
44.4 |
50 |
77 |
1450 |
37.0 |
5.5 |
PBG125-200A |
150 |
41.7 |
44 |
76 |
1450 |
30.0 |
5.5 |
PBG125-200B |
138 |
38.3 |
37.5 |
75 |
1450 |
22.0 |
5.5 |
PBG150-200 |
200 |
55.6 |
12.5 |
78 |
1450 |
15.0 |
5.0 |
PBG150-200A |
179 |
49.7 |
10 |
76 |
1450 |
11.0 |
5.0 |
PBG150-250 |
200 |
55.6 |
20 |
79 |
1450 |
18.5 |
5.0 |
PBG150-250A |
184.4 |
51.2 |
17 |
78 |
1450 |
15.0 |
5.0 |
PBG150-250B |
167 |
46.4 |
14 |
76 |
1450 |
11.0 |
5.0 |
PBG150-315 |
200 |
55.6 |
32 |
78 |
1450 |
30.0 |
5.5 |
PBG150-315A |
187 |
51.9 |
28 |
77 |
1450 |
22.0 |
5.5 |
PBG150-315B |
173 |
48.1 |
24 |
76 |
1450 |
18.5 |
5.5 |
PBG150-400 |
200 |
55.6 |
50 |
75 |
1450 |
45.0 |
5.5 |
PBG150-400A |
187 |
51.9 |
44 |
74 |
1450 |
37.0 |
5.5 |
PBG150-400B |
174 |
48.3 |
38 |
73 |
1450 |
30.0 |
5.5 |
PBG150-400C |
160 |
44.4 |
32 |
71 |
1450 |
22.0 |
5.5 |
PBG200-200 |
200 |
55.6 |
12.5 |
78 |
1450 |
15.0 |
5.0 |
PBG200-200A |
179 |
49.7 |
10 |
76 |
1450 |
11.0 |
5.0 |
PBG200-250 |
200 |
55.9 |
20 |
79 |
1450 |
18.5 |
5.0 |
PBG200-250A |
184.4 |
51.2 |
17 |
78 |
1450 |
15.0 |
5.0 |
PBG200-250B |
167 |
46.4 |
14 |
76 |
1450 |
11.1 |
5.0 |
PBG200-315 |
200 |
55.6 |
32 |
78 |
1450 |
30.0 |
5.5 |
PBG200-315A |
187 |
51.9 |
28 |
77 |
1450 |
22.0 |
5.5 |
PBG200-315B |
173 |
48.1 |
24 |
76 |
1450 |
18.5 |
5.5 |
PBG200-400 |
200 |
55.6 |
50 |
75 |
1450 |
45.0 |
5.5 |
PBG200-400A |
187 |
51.9 |
44 |
74 |
1450 |
37.0 |
5.5 |
PBG200-400B |
174 |
48.3 |
38 |
73 |
1450 |
30.0 |
5.5 |
PBG200-400C |
160 |
44.4 |
32 |
71 |
1450 |
22.0 |
5.5 |
PBG200-200(I) |
400 |
111.1 |
12.5 |
80 |
1450 |
22.0 |
5.5 |
PBG200-200(I)A |
358 |
99.4 |
10 |
78 |
1450 |
18.5 |
5.5 |
PBG200-250(I) |
400 |
111.4 |
20 |
80 |
1450 |
30.0 |
5.5 |
PBG200-250(I)A |
358 |
99.4 |
16 |
78 |
1450 |
22.0 |
5.5 |
PBG200-250(I)B |
322 |
89.4 |
13 |
75 |
1450 |
18.5 |
5.5 |
PBG200-315(I) |
400 |
111.4 |
32 |
80 |
1450 |
55.0 |
5.5 |
PBG200-315(I)A |
374 |
103.9 |
28 |
79 |
1450 |
45.0 |
5.5 |
PBG200-315(I)B |
346 |
96.1 |
24 |
78 |
1450 |
37.0 |
5.5 |
PBG200-400(I) |
400 |
111.4 |
50 |
81 |
1450 |
75.0 |
5.5 |
PBG200-400(I)A |
374 |
103.9 |
44 |
80 |
1450 |
75.0 |
5.5 |
PBG200-400(I)B |
346 |
96.1 |
30 |
78 |
1450 |
55.0 |
5.5 |
PBG200-400(I)C |
320 |
88.9 |
32 |
76 |
1450 |
45.0 |
5.5 |
PBG300-235 |
720 |
200 |
18 |
81 |
970 |
55.0 |
6.0 |
PBG300-235A |
657 |
182.5 |
15 |
79 |
970 |
45.0 |
6.0 |
PBG300-235B |
600 |
167.0 |
12.5 |
77 |
970 |
37.0 |
6.0 |
PBG300-300 |
720 |
200 |
28 |
81 |
970 |
75.0 |
6.0 |
PBG300-300A |
666 |
185 |
24 |
80 |
970 |
75.0 |
6.0 |
PBG300-300B |
623 |
173.1 |
21 |
79 |
970 |
55.0 |
6.0 |
PBG300-380 |
720 |
200 |
44 |
84 |
970 |
132.0 |
6.0 |
PBG300-380A |
666 |
185 |
38 |
80 |
970 |
110.0 |
6.0 |
PBG300-380B |
614 |
170.6 |
32 |
78 |
970 |
90.0 |
6.0 |
PBG300-235(I) |
1080 |
300 |
40 |
82 |
970 |
160.0 |
6.0 |
PBG300-235(I)A |
965 |
268.1 |
32 |
80 |
970 |
132.0 |
6.0 |
产品咨询
